Engineered for Tight Spaces, Perfected for Performance

Built for Demanding Installs

Designed to simplify service without compromising performance.

AL-FS is ALEDA’s premium aluminium die-cast front-service cabinet, crafted for performance-driven LED installations where precision, accessibility, and structural strength are non-negotiable. With its robust yet lightweight aluminium frame, AL-FS delivers superior heat dissipation, stability, and long-term durability. The front-service design allows technicians to access, maintain, or replace components without rear clearance, making it ideal for tight spaces like wall-mounted LED displays or architectural integrations.
Available in multiple size configurations 1280×1280, 960×960, 640×480, and 960×640, the AL-FS adapts to diverse project needs, from high-end retail interiors to corporate lobbies, broadcast studios, and public installations.

Category: Cabinet Type

ChatGPT Image Aug 25, 2025, 07_08_53 PM

Features — AL-FS

  • Aluminium Die-Cast Frame

    Lightweight yet robust, ensuring structural integrity and precision alignment.

  • Front-Service Access

    Enables quick maintenance from the front side without dismantling the installation

  • Multiple Size Options

    Available in 1280×1280, 960×960, 640×480, and 960×640 configurations.

  • Seamless Panel Alignment

    Maintains perfect pixel alignment across large video walls.

  • Enhanced Heat Dissipation

    Aluminium build helps regulate temperature for extended component lifespan.

Product Specifications

Type
Aluminium Die-cast Rear Service
Sizes
1280×1280, 960×960, 640×480, 960×640

An aluminium die-cast front service cabinet has an LED display
enclosure constructed from aluminium and is IP65 approved.
Designed for scenarios where rear access is limited, its “front
service” feature means all display components can be accessed
and maintained from the front, suitable for outdoor use.

Optimised for tight or inaccessible installation areas

Designed for fast, front-facing service

Built to keep pixel perfection intact

Ideal for both fixed and semi-permanent installs

Indoor Series

Crisp, high-definition LED displays for premium indoor environments.

Outdoor Series

Rugged, weather-proof LED solutions that perform under any sky.

Flex Series

LED panels that adapt to your creativity without limits.

Linear Lights

Sleek, uniform illumination for both functional and design-grade needs.

Cabinet Types

Sturdy, smart configurations like AL-FS, IR-RS that support versatile display installations.

Aluminium die-cast for a perfect balance of strength, durability, and light weight.

All components can be accessed from the front, removing the need for rear clearance.

Ideal for retail, lobbies, control rooms, museums, and tight installation areas.

Yes, available in multiple dimensions to suit various pixel pitches and applications.

Primarily for indoor and semi-outdoor installations, with IP-rated protection.

It dissipates heat effectively, keeping internal components cool and extending lifespan.

Yes, precision machining allows for seamless video wall assembly.

Much lighter, making it easier to handle during installation and servicing.

Yes, ALEDA offers project-specific adaptations where required.

Absolutely, works seamlessly with ALEDA’s LED modules and mounting systems.
